Engine
|
|
Internal Designation
|
M 56
|
Engine type
|
four-stroke two-cylinder flat-twin
|
Bore/stroke
|
78 x 78 mm
|
Cubic capacity
|
745 cm3
|
Max power
|
18 PS at 3400 U /min
|
Compression ratio
|
5,5 : 1
|
Valves per cylinder
|
sv
|
Carburation system
|
1 carburettor, Typ BMW Spezial two-valve 22 mm
|
Engine lubrication
|
forced-feed lubrication
|
Oil pump
|
gear pump
|
|
Power transmission
|
|
Clutch
|
single discs, dry - from engine no. 64101: two discs
|
Number of gears
|
3
|
Shifting
|
manual
|
Gear ratios
|
2,83 / 1,55 / 1,08
|
Rear wheel ratio
|
1 : 4,07 (sidecar 1 : 5,18)
|
Bevel/crown wheel
|
14 / 57 teeth (sidecar 11 / 57)
|
|
Electrical system
|
|
Alternator
|
magneto generator on request Bosch
|
Ignition
|
Bosch high-voltage magneto ignition
|
Spark plugs
|
Bosch W 175
|
|
Suspension
|
|
Designation
|
F 56
|
Type of frame
|
twin-loop steel tubular frame
|
Front suspension
|
plate spring, 6 laminae
|
Rear suspension
|
rigid
|
wheel rims
|
deep-bed 19 x 3
|
Tyres front
|
26 x 3,5 low pressure or 26 x 3,25 high pressure
|
Tyres rear
|
26 x 3,5 low pressure or 26 x 3,25 high pressure
|
Brakes front
|
drum brake ط 200 mm
|
Brakes rear
|
external shoe brake at gearing (on cardan shaft)
|
|
Dimensions and weights
|
|
Length x width x height
|
2100 x 800 x 950 mm
|
Wheel base
|
1400 mm
|
Tank capacity
|
12,5 l
|
Unladen weight, full tank
|
155 kg
|
Load rating
|
210 kg
|
Fuel consumption
|
ca. 5,0 l / 100 km
|
Oil consumption
|
ca. 1 - 2 l / 1000 km
|
Top speed
|
115 km/h
|
|
