Engine
|
|
Internal Designation
|
268 / 3
|
Engine type
|
four-stroke two-cylinder flat-twin
|
Bore/stroke
|
72 x 73 mm
|
Cubic capacity
|
594 cm3
|
Max power
|
42 PS at 7000 U /min
|
Compression ratio
|
9,5 : 1
|
Valves per cylinder
|
ohv
|
Carburation system
|
2 carburettor Bing 1/26/75 - 1/26/76 or 1/26/91 - 1/26/92
|
Engine lubrication
|
forced-feed lubrication
|
Oil pump
|
gear pump
|
|
Power transmission
|
|
Clutch
|
single disc saucer spring, dry
|
Number of gears
|
4
|
Shifting
|
foot Shifting
|
Gear ratios
|
4,17 / 2,73 / 1,94 / 1,54
|
Rear wheel ratio
|
1 : 3,13 or 1:3,375 (with sidecar 1 : 4,33)
|
Bevel/crown wheel
|
8 / 27 or 8 / 25 teeth (with sidecar 6 / 26)
|
|
Electrical system
|
|
Alternator
|
Bosch LJ/CGE 60/6/1700 R
|
Ignition
|
magneto ignition
|
Spark plugs
|
Bosch W 260 T 1 or Beru 260 / 14
|
|
Suspension
|
|
Designation
|
245/2
|
Type of frame
|
twin-loop steel tubular frame
|
Front suspension
|
long swinging arm with strut und oil-pressure shock absorbers
|
Rear suspension
|
long swinging arm with strut und oil-pressure shock absorbers
|
wheel rims
|
deep-bed 2,15B x 18, at sidecar, rear 2,75C x 18
|
Tyres front
|
3,50 x 18 S
|
Tyres rear
|
4,00 x 18 S
|
Brakes front
|
drum brake, Ø 200 mm Duplex full hub
|
Brakes rear
|
drum brake, Ø 200 mm Simplex full hub
|
|
Dimensions and weights
|
|
Length x width x height
|
2125 x 722 x 980 mm
|
Wheel base
|
1415 mm (with sidecar 1450 mm)
|
Tank capacity
|
17 l
|
Unladen weight, full tank
|
202 kg (with orig. BMW sidecar 324 kg)
|
Load rating
|
360 kg (with orig. BMW sidecar 600 kg)
|
idle/riding noise
|
84 / 82 DIN-phon (from13.9.1966: 78 / 84 dB(A))
|
Fuel consumption
|
ca. 5,3 l / 100 km
|
Oil consumption
|
ca. 0,5 - 1 l / 1000 km
|
Top speed
|
175 km/h
|
|
